PC/ABS

PC/ABS YF3100 NC

1104
  • Unit Price:
    ₫ 60.000 /KG
  • Packaging Specification:
    25KG/túi
  • Packaging Material:
    Túi giấy
  • Supply Quantity:
    10MT
  • COA Certificate:
    Provide
  • Place of Delivery:
    Miền Nam Việt Nam (xung quanh Hồ Chí Minh)
  • Material Comparison:
    PC/ABS TAIRILOY®  AC3100 FCFC TAIWAN

Material Description

  • Material Properties:Halogen miễn phí chống ch｜Tác động cao
  • Typical Applications:Thiết bị gia dụng cao cấp｜Ô tô/Phương tiện giao thô｜Thiết bị văn phòng｜Đèn chiếu sáng
  • Color:--
  • Grade:--

Material Certification

TDS

Technical Data Sheet Compare

flammabilityTest ConditionTest MethodTest Result
UL flame retardant rating

UL flame retardant rating

1.5mm

UL 94V-0
mechanical propertiesTest ConditionTest MethodTest Result
tensile strength

tensile strength

10mm/min

ISO 52756.5 Mpa
Elongation at Break

Elongation at Break

10mm/min

ISO 527107.2 %
bending strength

bending strength

10mm/min

ISO 17868.4 Mpa
Bending modulus

Bending modulus

10mm/min

ISO 1782231.6 Mpa
Impact strength of cantilever beam gap

Impact strength of cantilever beam gap

23℃

ISO 17949.3 kJ/m²
Rockwell hardness

Rockwell hardness

R

ISO 2039-2112 R
thermal performanceTest ConditionTest MethodTest Result
Hot deformation temperature

Hot deformation temperature

1.8MPa

ISO 7587.8 ℃
Physical propertiesTest ConditionTest MethodTest Result
melt mass-flow rate

melt mass-flow rate

260℃ × 2.16kg

ISO 113345 g/10min
density

density

23℃

ISO 11831.177 g/cm³
Shrinkage rate

Shrinkage rate

23℃

ISO 294-40.4-0.6 %
IMPORTANT NOTES: vnplas.com collected the data in the data sheet from the material manufacturers. vnplas.com makes the best effort to improve the accuracy of the data, but has no responsibility for the data. We strongly recommend verifying the validity of the data with the material manufacturers before making a final decision.
